WATER SAVING URINE ACTIVATED FLUSH SENSOR, 6STAR WELS

Description

6 STAR WELS Rated Urine activated Flush Sensor.

Urine Sensing Urinal Flush Valve and Sensor
ET3-M (must be mains powererd with backup battery) Ceramic sold separately

6 Star WELS efficiency Rating –  Specify where water efficiency or Green Star rating is the priority. Can be paired with or retrofitted to almost any urinal pan to achieve the most cost-effective and water efficient result.  All parts concealed, great for design and highly suitable for Commercial or Domestic use. It has 24-hour hygiene flush and stadium mode for high use situations. Can be installed behind in wall or in the ceiling.

Features

• Stadium Flush feature
• Automatic hygienic flush every 24 hours when not in use
• Suitable for top and back inlet
• Low energy consumption
• 6 Stars WELS rating
• AS/NZS 3982
• Watermark
• All parts concealed
• Urinal flush valve only – ceramic NOT included
• Technical Parameters
  • Power Input: 240V transformer and 6V battery back-up
  • Confirmation Time: detects constant flow 6 times in 5 seconds before flush
  • Minimum re-set of 10 seconds after flush
  • Detection zone – adjustable
  • Water Pressure – 100-500kPa (350kPa recommended)
  • Water Inlet – 15mm 1/2″ G
  • Water Temperature – 1-50°
  • Power Consumption Static: 4mA, active: 500mA
